RayTracer Studio

A real-time CPU-based ray tracer running in the browser via WebAssembly. Built with C++, Emscripten, and React.

🔗 Live Demo | Documentation

🎥 Watch Demo Video

Features

• CPU Ray Tracing - Pure C++ implementation compiled to WebAssembly
• Real-time Interactivity - Adjust light position and see immediate results
• Diffuse Shading - Lambertian lighting model
• Modern UI - Dark studio aesthetic with sleek controls

Prerequisites

• Node.js (v18+)
• Emscripten SDK - Installation Guide

Quick Start

1. Install Dependencies

npm install

2. Build the WebAssembly Module

Make sure Emscripten is installed and emcc is in your PATH:

# Activate Emscripten (if not already in PATH)
source /path/to/emsdk/emsdk_env.sh

# Build the WASM module
npm run build:wasm

3. Start Development Server

npm run dev

Open http://localhost:5173 in your browser.

Project Structure

RayTracer/
├── cpp/
│   ├── core.cpp          # Ray tracing engine
│   └── build.sh          # Emscripten build script
├── src/
│   ├── components/
│   │   ├── RaytracerCanvas.jsx
│   │   └── Controls.jsx
│   ├── wasm/
│   │   ├── raytracer.js      # Generated: WASM loader
│   │   └── raytracer.wasm    # Generated: WebAssembly binary
│   ├── App.jsx
│   ├── App.css
│   └── main.jsx
├── index.html
├── package.json
└── vite.config.js

How It Works

C++ Core

The ray tracer implements:

• Custom Vec3 struct with vector math operations
• Ray-sphere intersection using the quadratic formula
• Lambertian (diffuse) shading

WebAssembly Bridge

The C++ code is compiled to WebAssembly using Emscripten's embind:

• render(width, height) - Returns RGBA pixel buffer
• updateLight(x, y, z) - Updates global light position

React Frontend

• Loads WASM module asynchronously
• Renders to Canvas using putImageData
• Interactive sliders for light control

Scripts

Command	Description
npm run dev	Start Vite dev server
npm run build	Build for production
npm run build:wasm	Compile C++ to WASM
npm run preview	Preview production build

Tech Stack

• C++ - Core ray tracing logic
• Emscripten - C++ to WebAssembly compiler
• React 18 - UI framework
• Vite - Build tool with excellent WASM support

License

MIT

---

Made with ❤️ by SRS
